225
Integrator Mode
9) SCREEN MASK Setting
This function displays the inverse of the normal picture on the entire screen, or displays a single color such as white,
red, green, blue or yellow according to an internal signal in the Plasma Display.
When setting something other than ‘OFF’ or ‘INVERSE’ it is not possible to display a signal input.
When the screen has been burned, this function may be used as an emergency measure for relieving the problem (It
is not possible to completely remove the burning).
For details, refer to section 5.6, “Screen Burning” (pg. 283).
Factory setting: OFF
1 Enter the integrator mode.
(Refer to section 5.4.1, “About the Integrator Mode” (pg. 214).)
2 Select ‘OPTION’.
3 Place the cursor on ‘SCREEN MASK’ then press the [SET]
button to change the setting.
Each time the [SET] button is pressed, the setting changes
as shown below.
OFF: The normal display appears.
INVERSE: The RGB levels of the display are reversed with
respect to the normal display.
WHITE, RED, GREEN, BLUE, YELLOW: Only the selected color is displayed.
Note
In a mode other than OFF, operation is performed after the OSD display ends.
The ‘SCREEN MASK’ setting is common for all inputs.
INTEGRATOR INPUT1
CHANGE
SCREEN SETUP OPTIONPICTURE
SET EXITMENU
PROGRAM T I MER
SCREEN MASK
S I DE MASK
V I DEO WALL
BAUD RATE
I D NO. SET
:
:
:
GREEN
01H
38400BPS
Screen 3
WHITE
INVERSE
OFF
3
3
RED
GREEN
BLUE
3
YELLOW
3
222
