12.16
ELECTRICAL
Bumper Lights Relay
The bumper lights relay provides power to the following
system:
• Front Bumper Head Lights
Start Solenoid Relay
The start solenoid relay provides power to the following system:
• Starter Motor Solenoid
Power Steering Relay
NOTE: The power steering relay is not located
inside the fuse box.
The power steering relay provides power to the following
system:
• Power Steering Drive Motor
Bumper Lights Relay
Color Function
RD / BRN
20A fuse-protected 12 Vdc battery
voltage.
BRN Ground for relay coil.
DG
Hi/Low LH control 12 Vdc battery
voltage to relay coil.
DG LH / RH front bumper lights power.
Start Solenoid Relay
Color Function
RD / WHT
20A circuit breaker-protected 12 Vdc
battery voltage.
BRN / WHT ECU relay control for relay coil.
WHT / RD Starter solenoid power.
BLU / RD
Key-switched (START) relay coil power
12 Vdc battery voltage.
Power Steering Relay
Color Function
ORG (85)
LH RUN switch supplied 12 Vdc battery
voltage to relay coil.
BRN Relay coil ground.
ORG (87) Power steering 12 Vdc battery power.
RD
30A fuse-protected 12 Vdc battery
voltage.
