BODY/STEERING/SUSPENSION
5.3
BODY/PANEL REMOVAL
To Remove: Perform These Steps:
Seat Remove: Pull up on front of seat and then pull forward.......................
Console Remove: Gear selector handle....................
Console Screws
Disconnect dash component wires
Steering wheel (1 nut)
Rivets
Hood Disconnect: Headlights......................
4 hinge screws
Cab Remove: Seats.......................
Bolts of front mounts
Bolts for the rear mounts
Hood Liner Remove: Liner darts.................
Liner screws
Disconnect wiring harnesses
Remove air baffling boxes
Front Bumper Remove: Hood...............
3 front Torx screws from LH and RH wheel well panels
2 top bumper mounting bolts
3 lower bumper mounting bolts
Cargo Box Place box in the down position...........................
Raise rear of box with assist from dump box shocks
Remove hitch pins from shocks at box
Remove clevis pins
Disconnect light harnesses
Remove (2) screws holding hinge pins
Tap out hinge pins
Lift box off frame with assistance
Fuel Tank Raise rear box.........................
Disconnect vent and fuel lines (Note locations)
Disconnect electrical connection
Remove tank strap bolts, and tank straps
Lift tank out --through backside of compartment
