CLUTCH
6.7
PVT SEALING AND DUCTING COMPONENTS
DRIVE CLUTCH EXPLODED
VIEW
Drive Clutch
Mark with permanent
marker before disassembly
Tef l ont coated
brass bushing
Tef l ont coated
brass bushing
PVT Outer Cover
Cover Bolts
Inner Cover
Inner Cover Seal
Retainer
Outer Cover Seal
Clutch Outlet Duct
Clamps
