BRAKES
9.9
PARKING BRAKE LOCK
EXPLODED
VIEW
Main Parking
Brake Cable
Nylok Nut
Brake Lever Nut
Park Brake Cable
Equalizer and Pin
Assembly
Handle
Parking Brake
Rod
U--bolt
Catch Spring
Catch
W asher & Cotter Pin
Catch Plate
Bushing
W asher
Cotter Pin
Foot Lever
Spring
Bushing
W asher
Clevis Pin
Nut
Nut
W asher & Cotter Pin
