Polaris RANGER 2x4 User Manual

3
ENGINE
3.1
CHAPTER 3
ENGINE
Torque Specifications 3.2........................
Special Tools 3.2...............................
Service Data . . 3.3-3.4..............................
Torque Patterns 3.5.............................
Piston Identification 3.5..........................
Cooling System Pressure Test 3.6--3.7................
Cooling System Specifications 3.7................
Engine Removal 3.7............................
Engine Installation Notes 3.8.....................
Cylinder Honing 3.8--3.9.............................
Crankshaft Runout Inspection 3.9--3.10.................
Engine Lubrication 3.10..........................
Oil Pump Priming Procedure 3.10..................
Lubrication/Oil Flow 3.11-3.12.........................
Engine Exploded View 3.13.......................
Engine Top End Disassembly 3.14-3.23.................
Valve Seat Service 3.23-3.26..........................
Cylinder Head Assembly 3.26-3.31.....................
Engine Bottom End Disassembly 3.31-3.36..............
Crankcase & Bearing Assembly 3.37--3.38...............
Crankshaft End Play Inspection 3.38 -3.39...............
Counter Balancer End Play Inspection. 3.40.........
Oil Pump Shaft End Play Inspection 3.40--3.41...........
Engine Assembly/Inspection 3.41-3.51..................
Sealed Recoil Disassembly/Inspection 3.51--3.52.........
Sealed Recoil Assembly 3.52.....................
Spark Plug Fouling Checklist 3.53.................
Troubleshooting 3.53--3.54.............................
