9926814 R08 - 2015-2016 RZR 900 2016 RZR S 1000 Service

Manual

3.51

4. Using a commercially available strap wrench, hold

the flywheel and remove the flywheel retaining bolt

5. Fully install Flywheel Puller (PA-49316) on the

threads of the flywheel (left hand thread - turn

flywheel puller counterclockwise to install).

6. Hold puller body and tighten the center bolt

remove the flywheel.

Starter One-Way Clutch Inspection

NOTE

The starter one-way clutch can be serviced with the

engine installed in the chassis.

7. Remove the stator cover and flywheel (see Chapter

3 – Flywheel Removal, page 3.50.

8. Place flywheel on a work bench with the one-way

clutch facing up. Grasp clutch gear and rotate

clockwise. It should turn smoothly without binding.

9. Rotate one-way gear counterclockwise. The gear

should immediately lock in position and not slip.

10. Inspect the one-way gear bushing

for wear or

galling. If service is required, refer to “Starter One-

Way Clutch Disassembly”.

STARTER ONE-WAY CLUTCH DISASSEMBLY

1. Lift up to remove starter one-way gear.

2. Remove the three one-way clutch retaining screws.

ENGINE / COOLING SYSTEM
