FUSE / CIRCUIT BREAKER CIRCUITS
Fan – 20A Circuit Breaker
WIRE COLOR FUNCTION
Red
Power in from solenoid B
+
Orange / Black
Power to Fan Relay
EFI – 10A Fuse
WIRE COLOR FUNCTION
Red
Power from EFI Splice
Red Power to EFI Relay high
side
Key – 10A Fuse
WIRE COLOR FUNCTION
Red
Power from EFI Splice
Red / White
Power to B+ Unswitched
Splice #1
Term (Terminal Block) – 10A Fuse
WIRE COLOR FUNCTION
Red / Dark Green Power from Chassis
Splice
Orange / White Power to Key Acc Splice
Accessory – 10A Fuse
WIRE COLOR FUNCTION
Red
Power from Solenoid B+
Orange / White
Power to 12V Receptacle
Drive – 10A Fuse
WIRE COLOR FUNCTION
Red / Dark Green Power from Chassis
Splice
Red / Dark Green Power to AWD Coil
Lights – 15A Fuse
WIRE COLOR FUNCTION
Red / Dark Green Power from Chassis
Splice
Red / Yellow Power to Lights B+ Splice
EPS (if equipped) – 20A Fuse
WIRE COLOR FUNCTION
Red
Power from Solenoid B+
Red
Power to EPS Relay high
side
ELECTRICAL
