8
9926814 R08 - 2015-2016 RZR 900 2016 RZR S 1000 Service
Manual
© Copyright Polaris Industries Inc.
8.35
For DX bushing and seal style eyelet, follow the removal
procedures below.
1. Remove both dust seals from the eyelet.
2. Press out DX bushing using DX Bushing Press Kit
(803-00-935).
NOTE
DX Bushing style eyelets have larger bore diameters
than conventional eyelets.
3. Remove dust seal from bearing cap.
NOTE
On some models the seal may be in the bearing
assembly.
4. Remove low friction seal pack from bearing
assembly.
5. Remove U-Cup seal from bearing assembly. Note the
direction seal was installed.
6. Remove external O-ring from bearing assembly.
NOTE
If internal bearing is damaged, replace with complete
bearing assembly.
STEERING / SUSPENSION
