4.32
9924864 - 2012-2014 SPORTSMAN 800 / 6X6
© Copyright 2013 Polaris Sales Inc.
Ignition Coil Tests
The ignition coil can be tested by using an ohm meter.
Use the following illustration and specification table to
test the ignition coil resistance.
Ignition Coil Resistance Readings
TEST PIN CONNECTION RESISTANCE
Primary
Between 1 & 2
Between 2 & 3
0.4 Ω
Secondary
Between High Tension
Lead End Caps
Long: 2.46 kΩ ±6%
Short: 2.07 kΩ
±6%
Primary Test
Secondary Test
FUEL SYSTEM - GENERAL
