9924864 - 2012-2014 SPORTSMAN 800 / 6X6
© Copyright 2013 Polaris Sales Inc.
Middle Gearcase Exploded View
REF
QTY
DESCRIPTION REF
QTY
DESCRIPTION REF
QTY
DESCRIPTION
1 1 RH Gearcase 10 3
Bearing
18 1 Shim
2 1 LH Gearcase 11 1
Bushing
19 2
Plug, Hex Flange
3 1 Cover 12 2
Retaining Ring
20 2
O-ring
4 1 Shaft 13 1 Seal 21 1
Thrust Button
5
1
Gear, Drive
14 6 Bolt 22 1 Shim
6 1
Gear, Driven
15 1 Seal 23 1 Dowel Pin
7 1
Shaft, Pinion
16 2 Seal 24 1 Vent Tube
8 1
Gear, 31T
17 2
Bearing
25 6
Flange Bolt
9
1
Bearing
FINAL DRIVE
