6
6.19
9924864 - 2012-2014 SPORTSMAN 800 / 6X6
© Copyright 2013 Polaris Sales Inc.
Button To Tower Clearance Inspection
1. Inspect for any clearance between spider button to
tower. If clearance exists, replace all buttons and
inspect surface of towers. See “Spider Removal”
procedure.
Button to Tower Clearance:
000-.001”
2. Inspect sheave surfaces. Replace the entire clutch if
worn, damaged or cracked.
Bearing Inspection
1. Rotate non-braking clutch bearing in both clockwise
and counter-clockwise directions. The non-braking
bearing should rotate both directions on the shaft
with only a slight amount of drag.
2. Verify there is no binding or rough spots. If problems
are noted in either direction, continue with
disassembly.
CLUTCHING
