5
5.7
9924864 - 2012-2014 SPORTSMAN 800 / 6X6
© Copyright 2013 Polaris Sales Inc.
8. To reinstall the front bumper, reverse order of
removal. Be sure that the 4 plastic locking tabs of the
front fender are properly seated into the 4 slots of the
upper front bumper.
9. Torque the (6) T27 fasteners to specification.
Font Bumper Retaining Fasteners:
5 ft-lbs (7 Nm)
Mud Guard Removal / Installation
1. Remove front bumper as outline in this chapter.
2. Locate the mud guards in the front wheel area.
3. Remove the (1) T27 bolt and the (3) plastic rivets per
side.
4. Remove the wheel well from the vehicle frame.
5. Reverse this procedure to reinstall the mud guards.
6. Torque the T27 fasteners to specification.
Mud Guard Retaining Fasteners:
5 ft-lbs (7 Nm)
BODY / STEERING / SUSPENSION
