7.72
9924864 - 2012-2014 SPORTSMAN 800 / 6X6
© Copyright 2013 Polaris Sales Inc.
PROP SHAFT - FRONT OR REAR
Removal and Installation
1. Using Roll Pin Removal Tool (PN 2872608), remove
the roll pin from prop shaft at rear of housing (front
only) or transmission output shaft (rear only). Slide
prop shaft back and away from housing, then pull
sharply forward to remove from transmission shaft.
2. For installation, reverse the removal procedure.
NOTE: If removing rear propshaft, loosening
and/or removal of rear gearcase mounting bolts
may be required to gain necessary clearance for
propshaft removal.
FINAL DRIVE
