RADWAG AS X2 Series User Manual

- 103 -
24. COMMUNICATION
COMMUNICATION menu is comprised within Parameters menu. It is accessed by pressing key.
The balance can communicate with a peripheral device, wherein the communication is established
via the following ports:
• COM 1 (RS232),
• COM 2 (RS232),
• USB 1, type A
• USB 2, type B
• Ethernet,
• Wi-Fi.
The ports can be configured using <Communication> parameter group. To enter this submenu, press
key, next press “Communication” key.
CAUTION!
Communication via Ethernet does not refer to WLC X2 series.
24.1. RS 232 PORTS SETTING
Procedure:
• Select communication port <COM1> or <COM2>,
• Set appropriate values
The RS 232 ports enable the following setting of transmission parameters:
• Baud rate - 2400, 4800, 9600, 19200, 38400, 57600, 115200 bit/s
• Parity - None, Even, Odd
24.2. ETHERNET PORT SETTINGS
Procedure:
Select <
Ethernet> communication port, next set appropriate values:
• DHCP - Yes – No
• IP Address - 192.168.0.2
• Subnet mask - 255.255.255.0
• Default gate - 192.168.0.1
CAUTION!
Above settings serve information purposes only. Transmission parameters should be selected in accordance
with the settings of customer’s local network.
Ethernet port settings do not refer to WLC X2 series.
Return to weighing mode and restart the device.
24.3. WI-FI PORT SETTINGS
CAUTION!
1. Make sure that transmission parameters are accordant for your local network settings,
