RADWAG AS X2 Series User Manual

- 110 -
CAUTION: turn the continuous transmission off in order to provide correct cooperation
with E2R system.
• address
 parameter for setting address of balance connected with a computer
• weighing operation printout template
 parameter enabling you to design customized printout, for this use window with
printout template. For more information on designing printouts read section 14.3.
• continuous transmission, parameter enabling to turn on/off continuous transmission of a
weighing result, available options:
 continuous transmission in calibration unit, indications are transmitted in a main unit
(calibration) independently from currently selected weight unit,
 continuous transmission in current unit, indications are transmitted in a currently
selected weight unit, the transmitted unit changes along with the current unit change
(Units key),
 continuous transmission turned off <NONE>,
CAUTION!
Continuous transmission can be turned on/off by a respective message sent form a
computer (read COMMUNICATION PROTOCOL).
• interval
Parameter enables setting frequency of printouts for continuous transmission.
Frequency of printouts is set in seconds, wherein the accuracy is 0.1s.
you may set any time value ranging from 1000 to 0.1 s.
The setting is valid for continuous transmission in calibration unit and in current unit activated
by means of the balance, it is also valid for continuous transmission activated by command
sent from a computer.
25.2. PRINTER
Submenu <Printer> enables you to select a port to which data is sent upon pressing
key of a
balance keyboard. Content of sent data is set in <PRINTOUTS/GLP PRINTOUTS> parameter.
Procedure:
• press key
• enter <PERIPHERALS> menu
• next enter <PRINTER> menu
 set balance parameters related to cooperation with the printer; i.e. <PORT> to which a
printer is to be connected upon pressing button (printer connected), options:
 COM 1 or COM 2 – RS 232 port, the one to which a printer is connected
 USB type A – USB port, the one to which a PCL printer or EPSON printer is
connected
 Ethernet – port sending data to a dedicated RADWAG software, e.g. PW-WIN,
operated on a computer connected to a balance via network.
CAUTION: Communication via Ethernet does not refer to WLC X2 series.
 PENDRIVE – USB port type A for connecting USB flash drive.
 WIFI – port intended to enable sending data to RADWAG manufactured
software PW WIN (opened on computer connected to balance via Wi-Fi), to
printer featuring Wi-Fi port or to network printer.
 USB PC – port USB type B, intended for connection of computer with
RADWAG-invented PC software, e.g. PW-WIN.
An exemplary measurement printout is described in the PRINTOUTS section.
