7
ESP-LXME Controller
Storing the Programming Chart
Return the Programming Chart to a permanent, safe location when
you’re nished working with it. We recommend hanging it on the hook
inside the controller cabinet door as shown below.
Remote Programming
The ESP-LXME controller front panel can be programmed while
operating under battery power.
This feature is useful if the controller is installed in an area that is not
easily accessible. It also lets you enter program information before
installing the controller at the job site. All program information is stored
in nonvolatile memory so it will be preserved indenitely in the event
of a power outage or removal of the battery.
NOTE: Under battery power, all programs in progress will
continue to run in the controller memory, but irrigation will not
occur until power is restored. Without battery power, programs in
progress are cancelled.
A
Install a new 9-volt battery in the battery compartment in the
back of the front panel.
1
NOTE: To perform remote programming under battery power,
detach the front panel from the cabinet. See Access Controller
Cabinet in Section H for more details.
CAUTION: The controller can not run irrigation or system
diagnostics with the front panel detached. Re-connect the front
panel to the controller’s AC power source as soon as remote
programming is completed.
