Rain Bird ESP-LXME User Manual

63
ESP-LXME Controller
Station Flow Rates
Learn Flow Automatically (All Stations)

Turn the controller dial to Module Programming.
A
The Smart Module PGM screen appears with Flow Smart Module
selected; press Next.
B
The Flow Smart Module PGM screen appears. Press the Down
arrow to select Station Flow Rates; press Next.
1 2
C
The Set Flow Rates screen appears with Learn Flow selected; press
Next.
D
The Learn Flow screen appears with All Stations selected; press
Next.
3 4

NOTE: Ensure you have runtimes set up for all stations included
in a Learn Flow exercise prior to setting up a Learn Flow. Only
stations with run times will be included in Learn Flow operation.
E
A Learn Flow conrmation screen appears; press Next.
F
A second Learn Flow conrmation screen appears; press Next.
5 6
