46
ESP-LXME Controller
Station/MV Settings
Station Settings
The Station Settings option tells the ESP-LXME controller how to
interact with other stations, the master valve, and the weather
sensor.
Turn the controller dial to Station/MV Settings.
A
The Station/MV Settings screen appears with Station Settings
selected; press Next.
B
The Station Settings screen appears. Press the + and – buttons to
enter the desired station number; then press Next.
1 2
C
Press the + and – buttons to enter the number of valves connected
to the station; then press Next.
NOTE: Station Priorities are only used when Station Sequencing
is set to Sequence by Station Priority. If you’re using the default
Sequence by Station Numbers, then skip the next step by pressing
Next.
D
Press the + and – buttons to set Station Priority. Each station can
be set to High, Medium, Low or Non-irrigation. Station priority is
especially important when multiple programs run simultaneously.
When Station Sequencing is set to priorities, the controller will run
all high priority stations rst, then all medium and nally all low
priority, regardless of the station’s program settings. Press Next.
NOTE: Non-irrigation stations such as fountains and landscape
lighting receive priority to always run, regardless of weather
conditions.
3 4
NOTE: When using Station Sequencing by priorities, set station
priorities higher for stations you want selected earlier in a program
and lower for stations you want selected later in a program.
