Raymarine HSB Chartplotter User Manual

Chapter 6: Installation 101
SeaTalk
The SeaTalk standard was originally developed by Autohelm (part of the
Raytheon group), and allows compatible instruments to be connected by
a single cable carrying power and data in/out. This means that additional
instruments and functions can be added to a SeaTalk system, simply by
plugging them into the network.
SeaTalk is a precise, high-speed, bi-directional protocol which is flexible
enough to adapt to any number of instrument heads, without a central
processor. SeaTalk equipment can also communicate with non-SeaTalk
equipment via the NMEA standard.
12/24V Supply
SeaTalk
HSB
12/24V Supply
12/24V Supply
SeaTalk
SeaTalk
GPS
HSB Series Display
HSB Series Display
Course Computer
Distribution Panel
D4289-1
Scanner
SeaTalk
Integrated System with Repeater Display and SeaTalk Instruments
Data
Standards
