2 HSB Series Chartplotter
Note: Installation of all HSB display units is the same, whether the unit is
a chartplotter or a radar display. If you have both the
HSB Series
Pathfinder Radar
or the
HSB Series Chartplotter Handbook
you can
refer to either handbook for display unit installation details.
Terminology
The following terminology is used to describe chartplotter and radar
systems:
Master A unit capable of sourcing specific data
(such as radar or chart data).
Repeater A unit capable of displaying data, such as radar,
from the HSB.
Radar Display Unit providing Radar Master and Chart Repeater
functionality.
Chart Display Unit providing Chart Master and Radar Repeater
functionality.
Combined Display Unit providing both Radar and Chart Master
functionality.
Integrated System Additional instruments are connected via the
HSB, Seatalk or NMEA interfaces.
HSB™ High Speed Bus - links compatible display units.
For full display and control between HSB series
display units, the units must be connected via
HSB and SeaTalk.
General
The HSB Series Chartplotter, or combined Radar/Chartplotter display
unit is waterproof to CFR46 and can be installed either above or below
deck. The unit includes:
• 7" LCD display
• Chartholder compartment containing two slots for the C-MAP NT
®
electronic chart cards.
• Eleven dedicated (labelled) control keys.
• Four soft keys (unlabelled) whose functionality changes.
The display and keys can be illuminated for night-time use.
