Raymarine HSB Chartplotter User Manual

Chapter 3: Waypoints, Routes and Tracks
59
Adding Waypoints at the End of the Route
➤ To add waypoints at the end of the route:
1. Press the ROUTE soft key, followed by the EDIT ROUTE soft key.
The Make Route soft keys are displayed and the cursor is connected
to the last-placed waypoint with a dotted line. You can add further
waypoints to the route in the same way as for a new route.
2. Move the cursor to the required location, and press PLACE
WAYPOINT soft key.
If you place the waypoint in the wrong position, press the UNDO
WAYPOINT softkey.
Note: You can UNDO waypoints in the original route, not just the
new ones.
3. Place as many waypoints as required, and press the ACCEPT soft
key, then press ENTER to finish.
Removing a Waypoint from the Route
➤ To remove a waypoint from the current route:
1. Move the cursor over the required waypoint unitl the letters WPT are
displayed. The waypoint soft keys are displayed.
2. Press the REMOVE WAYPOINT soft key. The waypoint is removed
from the route and the route is re-numbered.
Alternatively, you can remove the last waypoint from a route by pressing
the UNDO WAYPOINT soft key, as described above in
Adding
Waypoints at the End of the Route .
If the route has
not been saved, the waypoint is erased.
If the route has been saved, the waypoint remains on the screen.
Reversing the Route
➤ To reverse the route, so you can Follow the route back:
1. Either press the ROUTE soft key followed by MORE, or
move the cursor over the required waypoint unitl the letters RTE are
displayed.
The route soft keys are displayed.
2. Press the REVERSE ROUTE soft key. The current route is reversed
on the screen.
Editing A Route
PLACE
WAYPOINT
UNDO
WAYPOINT
REMOVE
WAYPOINT
EDIT
ROUTE
REVERSE
ROUTE
ACCEPT
ROUTE
