64
HSB Series Chartplotter
GOTO
WAYPOINT
Stop Follow or
Stop Goto
2. Press the GOTO WAYPOINT soft key.
Navigation to the selected waypoint begins. The soft key STOP
GOTO is displayed.
3. To return to the default soft key display, move the cursor away from
the waypoint.
➤ To navigate directly to the cursor position:
1. Use the trackpad to position the cursor as required.
2. Press the GOTO default soft key, followed by GOTO CURSOR.
If navigation is currently in progress you are warned “Already
following route. Cancel route and goto cursor ?”.
To cancel the GOTO cursor operation, press NO.
To continue with the GOTO cursor operation (and stop the current
GOTO ROUTE), press YES.
The chartplotter places a temporary waypoint as the target and
starts to navigate towards it. The waypoint is shown as a square with
a dot in the centre, and is connected to the vessel’s starting position
with a dashed line.
The soft key STOP GOTO is displayed.
Note: The temporary waypoint is not added to the waypoint list;
when the GOTO is complete, or is stopped, the temporary waypoint
is erased.
3. To return to the default soft key display, move the cursor away from
the waypoint.
Stop Follow or Stop Goto
➤ To stop following the route or target point
either:
If necessary, press the GOTO soft key, then press the STOP
GOTO/FOLLOW soft key.
Or:
Move the cursor over any waypoint in the current route, then press
the STOP GOTO/FOLLOW soft key.
The dotted line from your vessel to the target waypoint disappears.
If you subsequently use the FOLLOW ROUTE soft key to restart
navigation, the route is followed from the point at which it was stopped.
This is indicated by a square around the target waypoint. If you want to
follow from another waypoint you can initiate the follow then use the
WAYPOINT ADVANCE soft key to step through the route.
STOP
GOTO
STOP
FOLLOW
FOLLOW
ROUTE
GOTO
CURSOR
GOTO
