Raymarine HSB Chartplotter User Manual

Chapter 3: Waypoints, Routes and Tracks
45
➤ To access waypoint soft keys, press MARKS:
D4169-1
PLACE WPT
AT CURSOR
PLACE WPT
AT VESSEL
WAYPOINT
LIST
Placing a Waypoint
The Place and Goto a Waypoint Scenario in Chapter 2 provides a
simple example of how to place a waypoint.
➤ To place a waypoint at the cursor position or at the vessel position:
1. Move the cursor to the required location, press MARKS.
2. Press either the PLACE WPT AT CURSOR or the PLACE WPT AT
VESSEL soft key.
The waypoint is added to the waypoint list and named using the next
available number.
The waypoint soft keys are displayed until you move the cursor away
from the waypoint. You can use the EDIT WAYPOINT soft key to
name the the waypoint as described in Editing Waypoints below.
➤ To place a waypoint using the Waypoint List:
1. Press MARKS, followed by the WAYPOINT LIST soft key. The
Waypoint List and associated soft keys are displayed.
GOTO
WAYPOINT
EDIT
WAYPOINT
MAKE NEW
WAYPOINT
WAYPOINT
TRANSFER
D4262-1
WAYPOINT LIST
SYMBOL NAME
WAYPOINT 001
WAYPOINT 002
WAYPOINT 003
WAYPOINT 004
WAYPOINT 005
50°21^966N
001°20^368W
POSITION
BRG _186°
BRG _21.0nm
TEMP
---°
C
DEPTH
---
m
DATE
--/--/--
TIME
--:--:--
PLACE WPT
AT CURSOR
WAYPOINT
LIST
PLACE WPT
AT VESSEL
Placing a
Waypoint
