Chapter 6: Installation 107
Console Mounting
The display unit can be console mounted if required, using the optional
flush-mounting kit (M92708).
CAUTION:
Make sure there are no hidden electrical wires or other items
behind the location before proceeding. Make sure there is
sufficient rear access for mounting and cabling.
1. Check the selected location for the unit. A clear, flat area at least
230mm (9in) wide by 210mm (8¼in) high, with at least 152mm (6in)
of clearance behind the panel, is required.
2. Unpack the flush-mounting kit.
3. Using the supplied template, trace out the display unit opening.
4. Drill a 12.7mm (½in) pilot hole in each opposing corner of the
cut-out area.
5. Using a suitable saw, cut along the inside edge of the cut-out line.
6. Remove the trunnion (yoke) knobs and bracket from the display unit.
Make sure that the unit fits in the cut-out area.
6a. If the optional screw fitting is required, drill four 5mm holes as
indicated on the template.
Screw the studs into the holes provided at the rear of the display.
7. Connect the DC power cable, and any other accessory cables to the
display avoiding tight bends in the cables.
8. Place the gasket on the unit and slide the unit into the panel cut-out.
9. Use the supplied kit to secure the unit to the console.
9a. Alternatively, fit a spacer over each of the four studs and secure with
the thumb nuts.
Console
Mounting
