16
HSB Series Chartplotter
Chart Simulator
When the simulator is switched on, your initial simulated position is
wherever the cursor was positioned. If you wish to practice using the
chartplotter in a particular chart area, use the trackpad to pan to the chart
area, then switch simulator ON.
If you have a combined Pathfinder radar/chartplotter display, or you are
using your chartplotter as a radar repeater you can also switch on the
radar simulator
➤ To view a chart (and radar) image using simulated data:
1. Press MENU followed by the SYSTEM SET UP soft key. The system
set up menu pop-up is displayed.
2. Use the trackpad to move the selection bar over the option
SIMULATOR. The simulator soft keys are displayed.
3. Press either DATA to view the chart with simulated navigation data ,
or BOTH to view simulated radar and navigation data.
4. Press ENTER twice to return to the default display.
Chart
Simulator
SYSTEM
SET UP!
BOTH
DATA
