Customising the Screen Presentation Options
The SCREEN soft key lets you set the following screen presentation
options on or off:
D4177-1
CRSR BOX
OFF ON
CHRT GRID
OFF ON
DATABOXES
OFF ON
CUSTOM
OFF ON
Cursor Data Box On and Off
The cursor data box provides the cursor’s position. If you wish to see a
full chart, you can switch the data box off. The cursor data can be set up
to appear in two data boxes; one showing range and bearing, the other
showing latitude and longitude. This option will switch them on and off as
a pair.
You can also move the cursor data box using the context-sensitive
cursor.
➤ To switch the cursor data box on/off:
1. Press the SCREEN soft key.
2. Press the CRSR BOX soft key to toggle the setting from ON to OFF
or from OFF to ON.
To return to the default soft key display, press ENTER.
Chart Grid On and Off
The chartplotter display includes grid lines of latitude and longitude
which you can use to help determine position on the chart. The grid lines
can be switched on if required.
➤ To switch the grid on or off:
1. Press the SCREEN default soft key.
2. Press the CHART GRID soft key to toggle the setting from OFF to
ON or from ON to OFF.
To return to the default soft key display, press ENTER.
Data Boxes
A group of up to six user-selected data boxes can be displayed, if the
information is available on your system. You select the data boxes in the
System Set Up menu as described in Chapter 5.
Customising
the Screen
SCREEN
CHRT GRID
OFF ON
SCREEN
CRSR BOX
OFF ON
