Printer Body
1. Top cover
Keep this cover closed during printing. If you cannot locate paper jams, or jammed paper cannot be removed easily, you
can check the condition of paper from the top of the printer.
2. Envelope selector
For envelopes, set the lever to the rear position
; for everything else, set the lever to the forward position .
3. Print cartridge (yellow)
4. Print cartridge (magenta)
5. Print cartridge (cyan)
6. Print cartridge (black)
7. Right front cover
Keep this cover closed during printing. Open to install or replace Print cartridges.
8. Tray 1
Load paper here.
9. Output tray extension
Pull out when using paper larger than Letter to keep the printed paper from falling.
10. Output tray
Prints are delivered to this tray.
When using paper larger than Letter, pull out the output tray extension.
