5. Press [Network Security Level].
6. Select the network security level you want.
Select [Level 0], [Level 1], [Level 2], or [FIPS140].
7. Press [OK].
8. Log out.
Specifying Network Security Level Using Web Image Monitor
1. Log in as the network administrator from Web Image Monitor.
2. Point to [Device Management], and then click [Configuration].
3. Click [Network Security] under "Security".
4. Select the network security level in "Security Level".
5. Click [OK].
6. "Updating..." appears. Wait for about one or two minutes, and then click [OK].
If the previous screen does not appear again after you click [OK], wait for a while, and then click
the web browser's refresh button.
7. Log out.
Status of Functions under Each Network Security Level
TCP/IP
Function Level 0 Level 1 FIPS 140 Level 2
TCP/IP Active Active Active Active
HTTP > Port 80 Open Open Open Open
SSL/TLS > Port 443 Open Open Open Open
5. Enhanced Network Security
78
