Ricoh MP C407 User Manual

3.SP Mode Tables
377
Drive Unit
Input Check
No. Part Name SP Name SP No. Reading
0 1
1 Fusing motor Fusing Motor: Lock 5-803-041 Lock Normal
2 Paper transport motor Transport Motor: Lock 5-803-042 Lock Normal
3 Development motor (CMY) FC Dev Motor: Lock 5-803-039 Lock Normal
4 Drum motor (CMY) FC Drum Motor: Lock 5-803-040 Lock Normal
5 Drum motor (K) Bk Drum Motor: Lock 5-803-038 Lock Normal
Output Check
No. Part Name SP Name SP
No.
Remark
1 Fusing motor Fusing Motor:
Standard Speed
1
5-
804-
029
Do not use these SPs, but use following SPs instead.
• SP1-158-001 (Abnormal Noise Confirmation: Unit:
Execute)
• SP1-158-002 (Abnormal Noise Confirmation: No Unit:
Execute)
A simple heater control is performed in these SPs, and
temperature rises excessively. It can cause the fusing sleeve
damaged.
Fusing Motor:
Low Speed
5-
804-
030
Fusing Motor:
Standard Speed
2
5-
804-
091
