Rigol DS1000Z Series Programming Guide

RIGOL Chapter 2 Command System
2-86 DS1000Z Programming Guide
:TRIGger:EDGe
Command List:
 :TRIGger:EDGe:SOURce
 :TRIGger:EDGe:SLOPe
 :TRIGger:EDGe:LEVel
:TRIGger:EDGe:SOURce
Syntax :TRIGger:EDGe:SOURce <source>
:TRIGger:EDGe:SOURce?
Description
Set or query the trigger source in edge trigger.
Parameter
Name
Type
Range
Default
<source> Discrete {CHANnel1|CHANnel2|CHANnel3|CHANnel4|AC} CHANnel1
Return
Format
The query returns CHAN1, CHAN2, CHAN3, CHAN4 or AC.
Example
:TRIGger:EDGe:SOURce CHANnel1
:TRIGger:EDGe:SLOPe
Syntax :TRIGger:EDGe:SLOPe <slope>
:TRIGger:EDGe:SLOPe?
Description
Set or query the edge type in edge trigger.
Parameter
Name
Type
Range
Default
<slope>
Discrete
{POSitive|NEGative|RFALl}
POSitive
Return
Format
The query returns POS, NEG or RFAL.
Example
:TRIGger:EDGe:SLOPe NEGative
Related
Command
:TRIGger:MODE
