Rigol DS1000Z Series Programming Guide

Chapter 2 Command System RIGOL
DS1000Z Programming Guide 2-113
:TRIGger:DELay (Option)
Command List:
 :TRIGger:DELay:SA
 :TRIGger:DELay:SLOPA
 :TRIGger:DELay:SB
 :TRIGger:DELay:SLOPB
 :TRIGger:DELay:TYPe
 :TRIGger:DELay:TUPPer
 :TRIGger:DELay:TLOWer
:TRIGger:DELay:SA
Syntax :TRIGger:DELay:SA <Source>
:TRIGger:DELay:SA?
Description
Set or query the trigger source A in delay trigger.
Parameter
Name
Type
Range
Default
<source>
Discrete
{CHANnel1|CHANnel2|CHANnel3|CHANnel4}
CHANnel1
Return
Format
The query returns CHAN1, CHAN2, CHAN3 or CHAN4.
Example
:TRIGger:DELay:SA CHANnel2
:TRIGger:DELay:SLOPA
Syntax :TRIGger:DELay:SLOPA <slope>
:TRIGger:DELay:SLOPA?
Description
Set or query the edge type of the trigger source A in delay trigger.
Parameter
Name Type Range Default
<slope> Discrete {POSitive|NEGative} POSitive
Return
Format
The query returns POS or NEG.
Example
:TRIGger:DELay:SLOPA NEGative
:TRIGger:DELay:SB
Syntax :TRIGger:DELay:SB <source>
:TRIGger:DELay:SB?
Description
Set or query the trigger source B in delay trigger.
Parameter
Name
Type
Range
Default
<source>
Discrete
{CHANnel1|CHANnel2|CHANnel3|CHANnel4}
CHANnel2
Return
Format
The query returns CHAN1, CHAN2, CHAN3 or CHAN4.
Example
:TRIGger:DELay:SB CHANnel2
