Rigol DS1000Z Series Programming Guide

RIGOL Chapter 2 Command System
2-54 DS1000Z Programming Guide
:MEASure:SOURce
Syntax :MEASure:SOURce <sour>
:MEASure:SOURce?
Description
Set or query the source of the current measurement parameter.
Parameter
Name
Type
Range
Default
<sour>
Discrete
{CHANnel1|CHANnel2|CHANnel3|CHANnel4}
CHANnel1
Explanation This command is used to set the source for the measurement parameters (except the
delay and phase). The delay and phase measurements requires two sources which can be
set by the
:MEASure:SETup:DSA and :MEASure:SETup:DSB, :MEASure:SETup:PSA
and :MEASure:SETup:PSB commands respectively.
Return
Format
The query returns CHAN1, CHAN2, CHAN3 or CHAN4.
Example
:MEASure:SOURce CHANnel2
Related
Commands
:MEASure:SETup:PSA
:MEASure:SETup:PSB
:MEASure:SETup:DSA
:MEASure:SETup:DSB
:MEASure:ITEM
:MEASure:COUNter:SOURce
Syntax :MEASure:COUNter:SOURce <sour>
:MEASure:COUNter:SOURce?
Description
Set or query the source of the frequency counter, or disable the frequency counter.
Parameter
Name
Type
Range
Default
<sour> Discrete {CHANnel1|CHANnel2|CHANnel3|CHANnel4|OFF} OFF
Return
Format
The query returns CHAN1, CHAN2, CHAN3, CHAN4 or OFF.
Example
:MEASure:COUNter:SOURce CHANnel2
Related
Command
:MEASure:COUNter:VALue?
:MEASure:COUNter:VALue?
Syntax
:MEASure:COUNter:VALue?
Description
Query the measurement result of the frequency counter. The default unit is Hz.
Return
Format
The query returns the measurement result in scientific notation. If the frequency counter
is disabled, 0.0000000e+00 will be returned.
Example
:MEASure:COUNter:VALue? /*The query returns 1.000004e+03*/
Related
Command
:MEASure:COUNter:SOURce

Rigol DS1000Z Series Specifications

General

Sample Rate	1 GSa/s (single channel), 500 MSa/s (dual channel)
Memory Depth	12 Mpts (standard), 24 Mpts (optional)
Vertical Sensitivity	1 mV/div to 10 V/div
Vertical Resolution	8 bits
Timebase Range	5 ns/div to 50 s/div
Channels	2 or 4
Display	7 inch color display
Trigger Modes	Edge, Pulse, Video
Connectivity	USB Host, USB Device, LAN (LXI)
Waveform Capture Rate	30, 000 wfms/s
Input Impedance	1 MΩ
Power Supply	100-240 VAC, 45-440 Hz
