Rigol DS1000Z Series Programming Guide

Chapter 2 Command System RIGOL
DS1000Z Programming Guide 2-31
:DISPlay:TYPE
Syntax :DISPlay:TYPE <type>
:DISPlay:TYPE?
Description
Set or query the display mode of the waveform on the screen.
Parameter
Name
Type
Range
Default
<type>
Discrete
{VECTors|DOTS}
VECTors
Explanation  VECTors: the sample points are connected by lines. Normally, this mode can provide
the most vivid waveform to view the steep edge of the waveform (such as the square
waveform).
 DOTS: display the sample points directly. You can directly view each sample point
and use the cursor to measure the X and Y values of the sample point.
Return
Format
The query returns VECT or DOTS.
Example
:DISPlay:TYPE DOTS
:DISPlay:GRADing:TIME
Syntax :DISPlay:GRADing:TIME <time>
:DISPlay:GRADing:TIME?
Description
Set or query the persistence time. The default unit is s.
Parameter
Name
Type
Range
Default
<time>
Discrete
{MIN|0.1|0.2|0.5|1|5|10|INFinite}
MIN
Explanation  MIN: set the persistence time to its minimum to view the waveform changing in high
refresh rate.
 Specific Values: set the persistence time to one of the values listed above to observe
glitch that changes relatively slowly or glitch with low occurrence probability.
 INFinite: in this mode, the oscilloscope displays the newly acquired waveform
without clearing the waveform formerly acquired. Enable to measure noise and jitter
as well as capture incidental events.
Return
Format
The query returns the persistence time currently set.
Example
:DISPlay:GRADing:TIME 0.1 /*Set the persistence time to 0.1s*/
:DISPlay:WBRightness
Syntax :DISPlay:WBRightness <time>
:DISPlay:WBRightness?
Description Set or query the waveform brightness. The default unit is %.
Parameter
Name
Type
Range
Default
<time>
Integer
0 to 100
50
Return
Format
The query returns an integer between 0 and 100.
Example
:DISPlay:WBRightness 60

Rigol DS1000Z Series Specifications

General

Sample Rate	1 GSa/s (single channel), 500 MSa/s (dual channel)
Memory Depth	12 Mpts (standard), 24 Mpts (optional)
Vertical Sensitivity	1 mV/div to 10 V/div
Vertical Resolution	8 bits
Timebase Range	5 ns/div to 50 s/div
Channels	2 or 4
Display	7 inch color display
Trigger Modes	Edge, Pulse, Video
Connectivity	USB Host, USB Device, LAN (LXI)
Waveform Capture Rate	30, 000 wfms/s
Input Impedance	1 MΩ
Power Supply	100-240 VAC, 45-440 Hz
