Chapter 2 Command System RIGOL
DS1000Z Programming Guide 2-57
:MEASure:SETup:MAX
Syntax :MEASure:SETup:MAX <value>
:MEASure:SETup:MAX?
Description Set or query the upper limit of the threshold in the time, delay and phase measurements.
The default unit is %.
Parameter
Name
Type
Range
Default
<value> Integer 7 to 95 90
Explanation  The upper limit, middle point and lower limit of the threshold (expressed in %) are
used to define the time, delay and phase parameters. Setting these values will affect
the measurement results of the time, delay and phase parameters.
 Setting the upper limit lower than the middle point will automatically reduce the
middle point to keep it lower than the upper limit.
Return
Format
The query returns an integer between 7 and 95.
Example
:MEASure:SETup:MAX 95
Related
Commands
:MEASure:SETup:MID
:MEASure:SETup:MIN
:MEASure:ITEM
:MEASure:SETup:MID
Syntax :MEASure:SETup:MID <value>
:MEASure:SETup:MID?
Description
Set or query the middle point of the threshold in the time, delay and phase
measurements. The default unit is %.
Parameter
Name
Type
Range
Default
<value>
Integer
6 to 94
50
Explanation  The upper limit, middle point and lower limit of the threshold (expressed in %) are
used to define the time, delay and phase parameters. Setting these values will affect
the measurement results of the time, delay and phase parameters.
 The middle point must be lower than the upper limit and greater than the lower limit.
Return
Format
The query returns an integer between 6 and 94.
Example
:MEASure:SETup:MID 89
Related
Commands
:MEASure:SETup:MAX
:MEASure:SETup:MIN
:MEASure:ITEM
