Rigol DS1000Z Series Programming Guide

RIGOL Chapter 2 Command System
2-82 DS1000Z Programming Guide
:TIMebase[:MAIN]:SCALe
Syntax :TIMebase[:MAIN]:SCALe <scale_value>
:TIMebase[:MAIN]:SCALe?
Description
Set or query the main timebase scale. The default unit is s/div.
Parameter
Name
Type
Range
Default
<scale_value> Real Normal: 5ns to 50s in 1-2-5 step
Roll: 200ms to 50s in 1-2-5 step
1μs
Explanation When the horizontal timebase mode is YT and the horizontal timebase is 20ms or
larger (namely the “Slow Sweep” mode), this command is invalid when the
oscilloscope in the Stoping state.
Return Format
The query returns the main timebase scale in scientific notation.
Example :TIMebase:MAIN:SCALe 0.0002 /*Set the main timebase scale to 200μs*/
:TIMebase:MAIN:SCALe? /*The query returns 2.0000000e-04*/
Related
Command
:TIMebase:MODE
:TIMebase:MODE
Syntax :TIMebase:MODE <mode>
:TIMebase:MODE?
Description
Set or query the mode of the horizontal timebase.
Parameter
Name
Type
Range
Default
<mode>
Discrete
{MAIN|XY|ROLL}
MAIN
Return Format The query returns MAIN, XY or ROLL.
Example
:TIMebase:MODE XY
Related
Commands
:TIMebase:DELay:OFFSet
:TIMebase:DELay:SCALe
:TIMebase[:MAIN]:OFFSet
:TIMebase[:MAIN]:SCALe

Rigol DS1000Z Series Specifications

General

Sample Rate	1 GSa/s (single channel), 500 MSa/s (dual channel)
Memory Depth	12 Mpts (standard), 24 Mpts (optional)
Vertical Sensitivity	1 mV/div to 10 V/div
Vertical Resolution	8 bits
Timebase Range	5 ns/div to 50 s/div
Channels	2 or 4
Display	7 inch color display
Trigger Modes	Edge, Pulse, Video
Connectivity	USB Host, USB Device, LAN (LXI)
Waveform Capture Rate	30, 000 wfms/s
Input Impedance	1 MΩ
Power Supply	100-240 VAC, 45-440 Hz
