Rigol DS1000Z Series Programming Guide

Chapter 2 Command System RIGOL
DS1000Z Programming Guide 2-67
[:SOURce[<n>]]:OUTPut[<n>][:STATe]
Syntax [:SOURce[<n>]]:OUTPut[<n>][:STATe] <bool>
[:SOURce[<n>]]:OUTPut[<n>][:STATe]?
Description Turn on or off the output of the specified source channel, or query the status of the output
of the specified source channel.
Parameter
Name
Type
Range
Default
[<n>] Discrete {1|2}
If omitted, the operation is
performed on source 1 by
default
<bool>
Bool
{{0|OFF}|{1|ON}}
0|OFF
Explanation [:SOURce[<n>]] and [<n>] are used to specify the source channel. The former enjoys
higher priority over the latter, namely if [:SOURce[<n>]] is omitted, the channel is
specified by [<n>] and if [:SOURce[<n>]] is not omitted, the channel is specified by
[:SOURce[<n>]]. If both are omitted, the operation is performed on source 1 by default.
Return
Format
The query returns OFF or ON.
Example
:OUTPut 1
[:SOURce[<n>]]:OUTPut[<n>]:IMPedance
Syntax [:SOURce[<n>]]:OUTPut[<n>]:IMPedance <impedance>
[:SOURce[<n>]]:OUTPut[<n>]:IMPedance?
Description
Set or query the impedance of the specified source channel.
Parameter
Name
Type
Range
Default
[<n>] Discrete {1|2}
If omitted, the operation is
performed on source 1 by
default
<impedance>
Discrete
{OMEG|FIFTy}
OMEG
Explanation  OMEG: high impedance; FIFTy: 50Ω
 [:SOURce[<n>]] and [<n>] are used to specify the source channel. The former
enjoys higher priority over the latter, namely if [:SOURce[<n>]] is omitted, the
channel is specified by [<n>] and if [:SOURce[<n>]] is not omitted, the channel is
specified by [:SOURce[<n>]]. If both are omitted, the operation is performed on
source 1 by default.
Return
Format
The query returns OMEG or FIFT.
Example :OUTPut:IMPedance FIFTy
