Rigol DS1000Z Series Programming Guide

RIGOL Chapter 2 Command System
2-58 DS1000Z Programming Guide
:MEASure:SETup:MIN
Syntax :MEASure:SETup:MIN <value>
:MEASure:SETup:MIN?
Description Set or query the lower limit of the threshold in the time, delay and phase measurements.
The default unit is %.
Parameter
Name
Type
Range
Default
<value>
Integer
5 to 93
10
Explanation  The upper limit, middle point and lower limit of the threshold (expressed in %) are
used to define the time, delay and phase parameters. Setting these values will affect
the measurement results of the time, delay and phase parameters.
 Setting the lower limit greater than the middle point will automatically increase the
middle point to keep it greater than the upper limit.
Return
Format
The query returns an integer between 5 and 93.
Example
:MEASure:SETup:MIN 93
Related
Commands
:MEASure:SETup:MAX
:MEASure:SETup:MID
:MEASure:ITEM
:MEASure:SETup:PSA
Syntax :MEASure:SETup:PSA <source>
:MEASure:SETup:PSA?
Description
Set or query source A of the Phase 1→2
and Phase 1→2 measurements.
Parameter
Name
Type
Range
Default
<source>
Discrete
{CHANnel1|CHANnel2|CHANnel3|CHANnel4}
CHANnel1
Return
Format
The query returns CHAN1, CHAN2, CHAN3 or CHAN4.
Example
:MEASure:SETup:PSA CHANnel1
Related
Command
:MEASure:ITEM
