Rigol DS1000Z Series Programming Guide

RIGOL Chapter 2 Command System
2-26 DS1000Z Programming Guide
:CURSor:XY
The :CURSor:XY commands can only be used when the horizontal timebase mode is XY.
Command List:
 :CURSor:XY:AX
 :CURSor:XY:BX
 :CURSor:XY:AY
 :CURSor:XY:BY
 :CURSor:XY:AXValue?
 :CURSor:XY:AYValue?
 :CURSor:XY:BXValue?
 :CURSor:XY:BYValue?
:CURSor:XY:AX
Syntax :CURSor:XY:AX <x>
:CURSor:XY:AX?
Description
Set or query the horizontal position of cursor A in the XY cursor measurement mode.
Parameter
Name
Type
Range
Default
<x> Integer 5 to 394 100
Explanation In the XY timebase mode, the horizontal and vertical positions of the cursor are defined
by the pixel coordinate of the XY display area. The pixel coordinate of the screen ranges
from (0,0) to (400,400). Wherein, (0,0) is located at the right top corner and (400,400) is
located at the left bottom corner. The horizontal and vertical pixel ranges are both from 0
to 400.
Return
Format
The query returns an integer between 5 and 394.
Example
:CURSor:XY:AX 200
:CURSor:XY:BX
Syntax :CURSor:XY:BX <x>
:CURSor:XY:BX?
Description
Set or query the horizontal position of cursor B in the XY cursor measurement mode.
Parameter
Name Type Range Default
<x> Integer 5 to 394 300
Explanation In the XY timebase mode, the horizontal and vertical positions of the cursor are defined
by the pixel coordinate of the XY display area. The pixel coordinate of the screen ranges
from (0,0) to (400,400). Wherein, (0,0) is located at the right top corner and (400,400) is
located at the left bottom corner. The horizontal and vertical pixel ranges are both from 0
to 400.
Return
Format
The query returns an integer between 5 and 394.
Example
:CURSor:XY:BX 200
