Rigol DS1000Z Series Programming Guide

Chapter 2 Command System RIGOL
DS1000Z Programming Guide 2-33
IEEE488.2 Common Commands
The IEEE 488.2 standard defines some common commands used for querying the basic information of the
instrument or executing the basic operations. These commands usually start with "*" and the keyword of
the command is usually 3-character long.
Command List:
 *CLS
 *ESE
 *ESR?
 *IDN?
 *OPC
 *RST
 *SRE
 *STB?
 *TST?
 *WAI
*CLS
Syntax
*CLS
Description
Clear all the event registers in the register set and clear the error queue.
*ESE
Syntax *ESE <value>
*ESE?
Description
Set or query the enable register for the standard event status register set.
Parameter
Name
Type
Range
Default
<value>
Integer
0 to 255
0
Explanation The bit 1 and bit 6 of the standard event status register are not used and are always
treated as 0, therefore, the range of <value> are the decimal numbers corresponding to
the binary numbers ranging from 00000000 (0 in decimal) to 11111111 (255 in decimal)
and of which the bit 1 and bit 6 are 0.
Return
Format
The query returns an integer which equals the sum of the weights of all the bits that have
already been set in the register.
Example *ESE 16 /*Enable the bit 4 (16 in decimal) of the standard event status register */
*ESE? /*The query returns 16*/

Rigol DS1000Z Series Specifications

General

Sample Rate	1 GSa/s (single channel), 500 MSa/s (dual channel)
Memory Depth	12 Mpts (standard), 24 Mpts (optional)
Vertical Sensitivity	1 mV/div to 10 V/div
Vertical Resolution	8 bits
Timebase Range	5 ns/div to 50 s/div
Channels	2 or 4
Display	7 inch color display
Trigger Modes	Edge, Pulse, Video
Connectivity	USB Host, USB Device, LAN (LXI)
Waveform Capture Rate	30, 000 wfms/s
Input Impedance	1 MΩ
Power Supply	100-240 VAC, 45-440 Hz
