Rigol DS1000Z Series Programming Guide

RIGOL Chapter 2 Command System
2-32 DS1000Z Programming Guide
:DISPlay:GRID
Syntax :DISPlay:GRID <grid>
:DISPlay:GRID?
Description
Set or query the grid type of screen display.
Parameter
Name
Type
Range
Default
<grid>
Discrete
{FULL|HALF|NONE}
FULL
Explanation FULL: turn the background grid and coordinate on.
HALF: turn the background grid off.
NONE: turn the background grid and coordinate off.
Return
Format
The query returns FULL, HALF or NONE.
Example :DISPlay:GRID NONE
:DISPlay:GBRightness
Syntax :DISPlay:GBRightness <brightness>
:DISPlay:GBRightness?
Description
Set or query the brightness of the screen grid. The default unit is %.
Parameter
Name
Type
Range
Default
<brightness> Integer 0 to 100 50
Return
Format
The query returns an integer between 0 and 100.
Example
:DISPlay:GBRightness 60

Rigol DS1000Z Series Specifications

General

Sample Rate	1 GSa/s (single channel), 500 MSa/s (dual channel)
Memory Depth	12 Mpts (standard), 24 Mpts (optional)
Vertical Sensitivity	1 mV/div to 10 V/div
Vertical Resolution	8 bits
Timebase Range	5 ns/div to 50 s/div
Channels	2 or 4
Display	7 inch color display
Trigger Modes	Edge, Pulse, Video
Connectivity	USB Host, USB Device, LAN (LXI)
Waveform Capture Rate	30, 000 wfms/s
Input Impedance	1 MΩ
Power Supply	100-240 VAC, 45-440 Hz
