:TRIGger:SPI (Option)
Command List:
 :TRIGger:SPI:SCL
 :TRIGger:SPI:SDA
 :TRIGger:SPI:WHEN
 :TRIGger:SPI:WIDTh
 :TRIGger:SPI:DATA
 :TRIGger:SPI:TIMeout
 :TRIGger:SPI:SLOPe
 :TRIGger:SPI:CLEVel
 :TRIGger:SPI:DLEVel
:TRIGger:SPI:SCL
Syntax :TRIGger:SPI:SCL <source>
:TRIGger:SPI:SCL?
Description
Set or query the channel source of SCL in SPI trigger.
Parameter
Name
Type
Range
Default
<source>
Discrete
{CHANnel1|CHANnel2|CHANnel3|CHANnel4}
CHANnel1
Return
Format
The query returns CHAN1, CHAN2, CHAN3 or CHAN4.
Example
:TRIGger:SPI:SCL CHANnel1 /*Set the channel source of SCL to CH1*/
:TRIGger:SPI:SDA
Syntax :TRIGger:SPI:SDA <source>
:TRIGger:SPI:SDA?
Description
Set or query the channel source of SDA in SPI trigger.
Parameter
Name
Type
Range
Default
<source>
Discrete
{CHANnel1|CHANnel2|CHANnel3|CHANnel4}
CHANnel2
Return
Format
The query returns CHAN1, CHAN2, CHAN3 or CHAN4.
Example
:TRIGger:SPI:SDA CHANnel2 /*Set the channel source of SDA to CH2*/
