Rigol DS1000Z Series Programming Guide

RIGOL Chapter 2 Command System
2-80 DS1000Z Programming Guide
:TIMebase Commands
The :TIMebase commands are used to set the horizontal parameters, such as enabling the delayed sweep
and setting the horizontal timebase mode.
Command List:
 :TIMebase:DELay:ENABle
 :TIMebase:DELay:OFFSet
 :TIMebase:DELay:SCALe
 :TIMebase[:MAIN]:OFFSet
 :TIMebase[:MAIN]:SCALe
 :TIMebase:MODE
:TIMebase:DELay:ENABle
Syntax :TIMebase:DELay:ENABle <bool>
:TIMebase:DELay:ENABle?
Description
Enable or disable the delayed sweep, or query the status of the delayed sweep.
Parameter
Name
Type
Range
Default
<bool>
Bool
{{0|OFF}|{1|ON}}
0|OFF
Explanation Delayed sweep can be used to enlarge a length of waveform horizontally to view the
waveform details.
Return Format
The query returns 0 or 1.
Example
:TIMebase:DELay:ENABle ON
:TIMebase:DELay:OFFSet
Syntax :TIMebase:DELay:OFFSet <offset>
:TIMebase:DELay:OFFSet?
Description
Set or query the delayed timebase offset. The default unit is s.
Parameter
Name
Type
Range
Default
<offset> Real -(LeftTime - DelayRange/2) to
(RightTime - DelayRange/2)
0
Explanation LeftTime = 6×MainScale – MainOffset
RightTime = 6×MainScale + MainOffset
DelayRange = 12×DelayScale
Return Format
The query returns the offset in scientific notation.
Example :TIMebase:DELay:OFFSet 0.000002 /*Set the delayed timebase offset to 2μs*/
:TIMebase:DELay:OFFSet? /*The query returns 2.0000000e-06*/
Related
Commands
:TIMebase:DELay:SCALe
:TIMebase[:MAIN]:OFFSet
:TIMebase[:MAIN]:SCALe
