d05786.fm
INSTALLATION MANUAL
BRP-Powertrain
Effectivity: 912 i Series
Edition 1/Rev. 2
76-00-00
Page 7
January 01/2014
2) FUSE BOX assy.
2.1) Technical data
Graphic See Fig. 3.
Connections and dimensions
Fig. 3
06330
Part Function
1 Plug connection POWER (X3)
271.8mm (10.70in.)
170mm (6.69in.)
1
86.8mm (3.42in.)
167mm (6.57in.)
151mm (5.95in.)
170mm (6.69in.)
ø5.5mm (0.22in.)
Regulator B
Regulator A
