INSTALLATION MANUAL
BRP-Powertrain
Effectivity: 912 i Series
Edition 1/Rev. 2
24-00-00
Page 35
January 01/2014
6) Internal power consumers
General note
Components Current consumption
NOTE: A complete analysis of the current consumption of all the
fitted consumers is to be carried out by the aircraft or air-
frame manufacturer.
Non-compliance can result in serious injuries or
death!
The current consumption of the remaining consumers
is to be limited so as to ensure that power is supplied
to the internal consumers (e.g. fuel pumps, ECU etc.)
at all times.
The battery and all loads in the aircraft must be di-
mensioned so, that even if one of the generators fails,
a safe flight is ensured.
See the performance diagrams of the internal and ex-
ternal alternators as a function of engine speed.
Components Current consumption
Fuel pump (main pump) min. 10 A
Fuel pump (additional pump) min. 10 A
ECU ~ 1.2 A
Warning lamp A max. 120 mA
Warning lamp B max. 120 mA
FUSE BOX ~ 400 mA
