INSTALLATION MANUAL
BRP-Powertrain
Effectivity: 912 i Series
Edition 1/Rev. 0
10-10-00
Page 6
January 01/2012
2) Engine suspension and installation position
General note
Engine suspen-
sion
The engine suspension is essentially determined by the aircraft design.
Eight attachment points are provided (4 on the engine if the ring mount is
used, if not: 2 on the engine and 2 on the engine suspension frame).
Engine suspen-
sion frame
The engine is supplied with a tested and certified suspension frame for the
fireproof bulk head. Installation in the aircraft is carried out using standard
captive rubber mounts which also isolate vibration and noise from the air-
craft frame.
2.1) Engine suspension instructions
General note
Noise emission
and vibration
During engine installation take into account the total
engine weight and ensure careful handling.
If the engine suspension frame is not used or if mod-
ified, certification in accordance with the latest regu-
lations, such as FAR or EASA, must be conducted by
the aircraft manufacturer.
The rubber mounts for neutralising vibrations and all
engine suspension components not in the scope of de-
livery must be ground run tested at the specified loads
and tested for vibration behaviour.
Certification to the latest regulations, such as FAR and
EASA, must be conducted by the aircraft manufactur-
er.
The engine suspension must be designed to prevent
excessive engine movement and to minimise noise
emission and vibration on the airframe.
If the GENUINE-ROTAX engine suspension frame is
not being used, a vibration test must be carried out.
See SL-912-010.
