Engineering manual - SAB 193-233-283 S A-frame (including ATEX)
100/175
008831 en 2022.02
Technical data
6.13 Noise data
Noise data is stated in:
SWL:
A-weighted sound power level
SPL:
A-weighted sound pressure level, in free field over reflecting plane (1 m distance).
• Noise data is based on measurements according to ISO 9614-2.
• The stated SPL values are calculated using the formula 8.3 in ISO 3744.
• The stated values are for a complete unit operating in 100% capacity.
6.14 Noise data for SAB 193-233-283
Evaporating temperature, TE -15°C
Condensing temperature, TC +35°C
Refrigerant R717/HCFC/HFC
Speed 2950 rpm
For 60 Hz-driven compressors, add + 2 dBA to the stated levels.
Type of unit
SWL SPL
SAB 193 S 103 84
SAB 193 L 104 84
SAB 233 S 105 86
SAB 233 L 106 86
SAB 233 E 107 86
SAB 283 S 106 88
SAB 283 L 107 88
SAB 283 E 108 88
SAB 283 X 108 88
Table 24: Noise data
Noise data for other operating conditions can be provided by Johnson Controls Denmark on
request.
Note:
• The actual SPL value on site will be between the stated SPL and SWL depending on
the acoustic environment in the machine room.
• In a typical machine room without any noise absorbing materials, the actual SPL will be
approximately 14 dBA higher than the stated SPL (free field value).
• Checking the actual SPL must therefore always be accompanied by measurements of
the acoustic environment of the machine room. Alternatively, ISO 9614-2 could be fol-
lowed at the installation site to obtain SWL comparable values.
• Be aware of local/national requirements for the use of ear protection. Generally, it is
recommended to use ear protection in machine rooms.
