I - 110
SM830063
ECO MULTI SYSTEM Unit Specifications
1
9-1. Specifications
Unit specifications (A)
9. Floor-Standing Type (F Type)
MODEL No. Indoor Unit SPW-FR93GH56
POWER SOURCE 220 - 230 - 240 V / 1 phase / 50Hz
PERFORMANCE Cooling Heating
Capacity kW 2.8 3.2
BTU / h 9,600 11,000
Air circulation (Hi / Me / Lo) m
3
/ h 420 / 360 / 300
Moisture removal (High) Liters / h 1.3 —
ELECTRICAL RATINGS
Voltage rating V 220 - 230 - 240
Available voltage range V 198 – 264
Running amperes
*
A 0.24 - 0.25 - 0.26 0.17 - 0.18 - 0.19
Power input W 51 - 56 - 61 36 - 40 - 45
Power factor % 96.6 - 97.4 - 97.8 96.3 - 96.6 - 98.7
Max. starting amperes A 1 - 1 - 1
FEATURES
Controls Microprocessor
Timer ON / OFF Timer (Max.72 hr)
Fan speeds 3 and Automatic control
Air filter Washable, easy access
Refrigerant control Electronic expansion valve
Operation sound (Hi / Me / Lo) dB-A 33 / 30 / 28
Refrigerant tubing connections Flare type
Refrigerant tube Narrow tube mm (in) 9.52 (3 / 8)
outer diameter Wide tube mm (in) 12.7 (1 / 2)
Drain connection 20A, OD26mm
Drain pump –
Drain pump (drain connection) Optional (RCS-SH80TG)
Remote controller (option) Optional / drain hose
Color (Approximate value) Munsell 10Y9.3 / 0.4, RAL 9010-GL
DIMENSIONS & WEIGHT Unit dimensions Package dimensions
Dimensions Height mm (in) 615 (24 - 7 /32) 694 (27 --10/32)
Width mm (in) 1065 ( 41 - 30 /32) 1157 (45 --18/32)
Depth mm (in) 230 ( 9 - 2 /32) 312 (12 - 9 /32)
Net weight kg (lb) 29 ( 64 )
Shipping weight kg (lb) 64 ( 68 )
Shipping volume m
3
(cu. ft) 0.251 ( 8.9 )
DATA SUBJECT TO CHANGE WITHOUT NOTICE.
Cooling :
Rating conditions(
*
) : Indoor air temperature 27 °C DB / 19 °C WB, Outdoor air temperature 35 °C DB
Heating :
Rating conditions(
*
) : Indoor air temperature 20 °C DB, Outdoor air temperature 7°C DB / 6°C DB
To Next Page
