SM830063
I - 139
1
ECO MULTI SYSTEM Unit Specifications
11-2. Major component specifications
Indoor unit (A)
11. 1-Way Air Discharge Semi-concealed-Slim Type (SL Type)
MODEL No. SPW-SLR93GH56
Source 220 - 230 - 240 V / 1 phase / 50Hz
Controller P.C.B. Ass’y CR-X253GH (Microprocessor)
Fan (Number…diameter) mm Centrifugal (3)
Fan motor
Model…Nominal output W SR4X - 31A3P... 30 W
Source 220 - 230 - 240 V / 1 phase / 50 Hz
No. of pole…r.p.m. (230 V, High) rpm. 4... 1.010
Coil resistance Ω WHT - BRN : 191.0 ORG - YEL : 40.0
(Ambient temperature 20 °C) WHT - VLT : 47.1 YEL - BLK : 96.5
VLT - ORG : 40.0 BLK - PNK : 44.7
Safety device
Operating temperature Open °C 130 ± 8
Close °C79± 15
Run capacitor VAC, µF 440 V, 1.2 µF
Electronic expansion valve
Solenoid control model DKV-MOZS550E0
Coil resistance (at 20 °C) Ω ORG – GRY : 46 , YEL – GRY : 46
RED – GRY : 46, BLK – GRY : 46
Solenoid control valve model IKV-24D12
Heat exchanger
Coil Aluminum plate fin / Copper tube
Rows…fin pitch mm 2…1.5
Face area m
2
0.145
Panel
Model No. PNR-SL183GHA
Auto louver motor MT8-3C
Auto louver motor…Rated V, W, rpm. 220 - 240 VAC, 3 W, 2.5 rpm
Coil resistance (at 25 °C) Ω 16.430 Ω ± 8 %
Drain Pump WP20SL-23
Rated V, W AC230 V, 50 Hz, 14.7 W
Total head & capacity 400 mm, 600 cc/min
