SM830063
I-59
1
ECO MULTI SYSTEM Unit Specifications
5-1. Specifications
Unit specifications (A)
MODEL No. Indoor Unit SPW-KR93GH56
POWER SOURCE 220 - 230 - 240 V / 1 phase / 50Hz
PERFORMANCE Cooling Heating
Capacity kW 2.8 3.2
BTU / h 9,600 11,000
Air circulation (Hi / Me / Lo) m
3
/ h 450 / 390 / 340
Moisture removal (High) Liters / h 1.3 —
ELECTRICAL RATINGS
Voltage rating V 220 - 230 - 240
Available voltage range V 198 – 264
Running amperes A 0.22 - 0.22 - 0.23 0.22 - 0.22 - 0.23
Power input W 47 - 50 - 54 47 - 50 - 54
Power factor % 97 - 98 - 98 97 - 98 - 98
Fan motor locked rotor amperes A 1 - 1 - 1
FEATURES
Controls Microprocessor
Timer ON / OFF Timer (Max. 72 hr)
Fan speeds (Indoor unit) 3 and Automatic control
Air filter Washable, easy access
Refrigerant control Electronic expansion valve
Operation sound (Hi / Me / Lo) dB-A 38 / 33 / 30
Refrigerant tubing connections Flare type
Refrigerant tube Narrow tube mm (in) 9.52 (3 / 8)
diameter Wide tube mm (in) 12.7 (1 / 2)
Drain connection 20 A, OD26 mm
Remote Controller Optional (RCS-SH80TG)
Refrigerant tubing kit / Accessories Optional / Hanging wall bracket
Color (Approximate value) Munsell 3.0Y8.6 / 0.8, RAL 1013-GL
DIMENSIONS & WEIGHT Unit dimensions Package dimensions
Dimensions Height mm (in) 360 (14 - 1 / 8) 282 ( 11 - 1 / 8)
Width mm (in) 1,000 (39 - 3 / 8) 1,080 ( 42 - 1 / 2)
Depth mm (in) 205 ( 8 - 1 /16) 443 ( 17 - 1 / 2)
Net weight kg (lb) 15 ( 33 )
Shipping weight kg (lb) 19 ( 42 )
Shipping volume m
3
(cu. ft) 0.135 ( 4.8 )
5. Wall Mounted Type
DATA SUBJECT TO CHANGE WITHOUT NOTICE.
Rated conditions
Cooling: Indoor air temperature 27 °CDB/19 °C WB, Outdoor air temperature 35 °C DB
Heating: Indoor air temperature 20 °C DB , Outdoor air temperature 7 °CDB/6 °CWB
